Galvanized & Galfan coated Steel wire
Link Middle East has a state of the art wire manufacturing facility capable of manufacturing Low Carbon & High Carbon Wire. The facility has an installed capacity of 3000 T per month & manufactures Wire from 0.9mm upto 6.0mm
Wire manufactured by us confirms major EM & ASTM standards.In addition, our experience of over 3 decades ensures that we take into account industry requirements with respect to specifications & delivery requirements.
Our Wire manufacturing Facilities include:
- Annealing
- Patenting
- Wax Coating
- Galvanizing (Commercial Coating, Heavy & Extra Heavy Coating)
- Galfan® Coating (95%Zn & 5% Al+Misch Metal Alloy)
-
Application
- Perimeter Security
- Packaging
- Gabions
- Steel Cables
- Weld Mesh
- Ropes
- Baling Wires
- Springs
- Cable trays
- Bedding Mattresses
- Power Cable Armouring
- Nails
- ACSR
- more….
-
Wire Range
Grades SAE 1005 to SAE 1085
Diameters 0.9mm to 6.0mm Annealing 0.9 to 6.0 mm Patenting 2.0 to 4.0 mmm -
Hot Dip Galvanized
Range
Diameter*
0.9mm to 6.0mm Tensile Strength* 350 to 550 Mpa; 550 to 770 MPa;
1100 to 1450MPa; 1450 to 1800 Mpa
Galvanizing
Commercial 30 to 80g/m2;
Conforming to EN 10244; ASTM 641 M
Medium
Heavy
125 to 180 g/m2; 180 to 300 g/m2
Conforming to EN 10244 & ASTM
Extra Heavy 300 to 610 g/m2 g/m2 DIN & ASTM * Tensile Range & Mass Of Coating for Galvanizing varies with Wire Diameter
-
Galfan Coated
Range
Diameter* 0.9mm to 5.0mm Tensile Strength*
350 to 550 Mpa; 550 to 770 MPa;
1100 to 1450MPa; 1450 to 1700 Mpa
Galfan Coating:
Confirming to EN 10244
Medium-Heavy 125 to 350 g/m2
Confirming to EN 10244
* Tensile Range & Mass Of Coating for Galvanizing varies with Wire Diameter
-
PVC Coated
Range
* Tensile Range & Mass Of Coating for Galvanizing varies with DiameterDiameter*
1.50/2.60mm to 4.0/5.0mm
Tensile Strength* 400 to 600 MPa Mass of Galvanizing / Galfan Coating 30 to 350 g/m2 EN 10244 -
